DESCRIPTION
TRACE ADVANCED – Unique to ZT – RMG First Focal Plane (FFP) reticle to meet the demands of the long range precision and PRS shooters alike. The TRACE ADVANCED gives shooters the ability to put rounds on target with speed, and most importantly, precision.
Whether holding elevation and windage for high speed, precision shots or dialing your turrets for long range targets, the RMG is the perfect blend of precision and speed.
Subtended in 0.5 mil increments with integrated 0.1 mil measuring bars, the RMG allows shooters to apply elevation and windage holds without having to dial the turrets. A floating center dot ensures a refined point of aim for zeroing and shooting groups, while the heavy bars with chevron ends at 3, 6, 9 and 12 o’clock help draw the shooter’s eye to the center of the reticle at lower magnifications.
SPECIFICATIONS
Focal Plane | First (FFP) |
Reticle calibrated magnification power (SFP only) | N/A |
Magnification Range | 4.5-27x |
Objective Lens Diameter | 50mm |
Maintube Diameter | 30mm |
Zero Stop | Yes |
Turret Index Value | 0.1MILS |
Internal Elevation Adjustment | 17.5MILS |
Internal Windage Adjustment | 16MILS |
Parallax Adjustment Range | 25 Meters – Infinity |
Exit Pupil Diameter | Low: 9.5mm; High: 1.9mm |
Eye Relief | 91-100mm |
Field Of View @100 Meters | Low:7.4m; High: 1.3m |
Objective Outer Diameter | 57.5mm |
Ocular Outer Diameter | 43.5mm |
Weight | 824g (1.8lbs) |
Available Reticles | RMG |
Illumination | No |
Light Transmission | 92% |
