DESCRIPTION
The Vortex Optics 45° angled viewing Razor HD 27-60x85 Spotting Scope is engineered with an oversized objective, superior glass and specialized optical coatings to provide clear and bright images at all magnifications and lighting conditions. The triplet apochromatic lens is made of High Density (HD) Extra-low Dispersion (ED) glass to increase light transmission, minimize distortion and virtually eliminate chromatic aberration. All air-to-glass surfaces have Vortex's XRPlus anti-reflective coatings to minimize light loss and maximize image brightness, while the Porro prisms have highly-reflective dielectric coatings which improve brightness, clarity, and color accuracy. This combination of coatings and optics create a spotting scope that produces bright, clear, high-contrast images with accurate color rendition.
OPTICAL FEATURES |
|
|
Triplet Apochromatic lens combines with HD glass to provide unmatched color sharpness. |
|
Premium HD (High Density) extra-low dispersion glass delivers the ultimate in resolution and color fidelity, resulting in High Definition images. |
|
Premium proprietary coatings deliver the highest level of light transmission with multiple anti-reflective coatings on all air-to-glass surfaces for maximum brightness. |
|
Multi-layer prism coatings provide bright, clear, color-accurate images. |
|
Cutting edge application process provides unparalleled coating durability and performance. |
CONSTRUCTION FEATURES |
|
|
Offers maximum image quality and performance in a traditional design. |
|
Valued for allowing an overall lower mounting height which maximizes stability in wind, offers greater comfort when glassing for extended periods, and permits the use of a smaller, lighter tripod. |
|
O-ring seals prevent moisture, dust and debris from penetrating the spotting scope for reliable performance in all environments. |
|
Argon gas purging prevents internal fogging over a wide range of temperatures. |
|
Ultra-hard, scratch-resistant coating protects exterior lenses from scratches, oil and dirt. |
CONVENIENCE FEATURES |
|
|
Twists up and down for comfortable viewing with or without eyeglasses. |
|
Allows for fast and fine adjustments. |
|
Reduces glare and shields the objective lens from raindrops and snow. |
|
Allows rotation of the eyepiece to a sideways position, providing adjustable viewing angles. |
Magnification | 27 - 60x |
Objective Lens Diameter | 85 mm |
Field of View | 117 - 68' @ 1000 yd / 39 - 23 m @ 1000 m |
Minimum Focus Distance | 16.4' / 5.0 m |
Exit Pupil Diameter | 3.1 - 1.4 mm |
Eye Relief | 17.0 - 16.7 mm |
Filter Thread | Not specified by manufacturer |
Mounting Thread | 1/4"-20 |
Weatherproofing | Argon-filled, water and fogproof |
Length | 15.5" / 39.4 cm |
Weight | 4.1 lb / 1.9 kg |
