DESCRIPTION
All models feature Hawke’s new H7 optics with high zoom ratio, supreme clarity and light transmission.
Supreme accuracy for rifle shooting, driven and hunting applications.
FEATURES
MIL FD RETICLE (10x)
Accurate mil spacing on 10x magnification. The bright fiber optic center dot gives a sharp aim point for quick reference and target acquisition. The thick outer posts make visibility easy when hunting in low-light conditions and a fine upper post ensures it doesn't obstruct your view of the target.
RETICLE SUBTENSIONS
When on 10x magnification, the gap between two marks is equal to 2 MOA of spacing.
SPECIFICATIONS
Objective Lens: | 24mm |
Reticle: | Mil FD (10x) |
Parallax: | Fixed |
Magnification: | 1-10x |
Optical System: | System H7 |
Focal Plane: | SFP (Second Focal Plane) |
Scope Tube: | 30mm |
Illumination: | 11 Levels - Red |
Field of View: | 38.8 - 3.9m @100m ( 116.3 - 11.6ft @100yds ) |
Field of View (°): | 21.9 - 2.2 |
Eye Relief: | 102mm ( 4" ) |
PX/Focus: | 91m ( 100yds ) |
Exit Pupil: | 24 - 2.4mm ( 0.94 - 0.09″ ) |
Turret Type: | Zero Lock 'n' Stop |
Click Value: | 1⁄ 10 MRAD |
Elevation Turret Clicks (max): | 40 MRAD |
Windage Turret Clicks (max): | 40 MRAD |
Ocular Type: | Locking Fast Focus |
Power Selector: | Knurled Posi-Grip with Removable Zoom Lever |
Lens Coating: | Fully Multi-Coated - 21 Layers |
Length: | 283mm ( 11.1" ) |
Weight: | 540g ( 19oz ) |
